CPU
Intel® Socket LGA 1851 for Intel® Core™ Ultra Processors (Series 2)
Chipset
Intel® Z890
MEMORY
DIMM Slots
4 x DDR5 only
Memory Architecture
Dual-Channel
Intel® Extreme Memory Profile (XMP) 3.0
Supported
OC Frequency
Please refer to Memory QVL on NZXT’s website (www.nzxt.com) for more information.
EXPANSION SLOTS
PCIe 5.0 ×16 slot (PCIEX16_1)
1 (×16 mode)
PCIe 4.0 ×16 slot (PCIEX16_2)
1 (×2 mode)
M.2 Socket (Key E)
1 (Type 2230 Wi-Fi/BT PCIe Wi-Fi module and Intel® CNVio/CNVio2)
STORAGE
M.2_1
Type 2280 (PCIe 5.0 ×4 mode)
M.2_2
Type 2280 (PCIe 4.0 ×4 mode)
M.2_3
Type 2280 (PCIe 4.0 ×4 mode)
M.2_4
Type 2280 (PCIe 4.0 ×4 mode)
M.2_5
Type 2280 (PCIe 4.0 ×4 mode)
SATA 6Gb/s ports
4
LAN
Realtek® 5.0G LAN
WIRELESS
Tri-Band Wi-Fi 7
Supported (320MHz)
Bluetooth
v5.4
AUDIO
Realtek® ALC4082 Audio Codec
REAR I/O
Wireless antenna SMA connectors
2
HDMI™ port
1
Thunderbolt™ 4 ports
2
USB 3.2 Gen 2×2 Type-C® port
1
USB 3.2 Gen 2 ports
6
USB 3.2 Gen 1 Type-A® ports
3
Clear CMOS button
1
LAN (RJ45) port
1
Audio jacks
2
Optical S/PDIF out port
1
INTERNAL I/O
24-pin ATX power connector
1
8-pin ATX 12V power connector
2
4-pin CPU_FAN connector
1
4-pin AIO_PUMP connector
1
4-pin SYS_FAN connectors
3
NZXT RGB LED connector
1
5V ARGB LED connectors
2
NZXT 8-pin PWM connectors
2
USB 2.0 header
2 (Up to 4 USB 2.0 ports)
USB 3.2 Gen1 header
2 (Up to 4 USB 3.2 Gen 1 ports)
USB 3.2 Gen2x2 front panel header
1 (For USB Type-C)
Front panel audio connector
1
Power button
1
Reset button
1
Post LEDs
1
Digital Debug LED
1
GENERAL
Operating System
Windows® 11/10 64-bit
Form Factor
ATX
Model Number
N9-Z89XT-W1 (White) / N9-Z89XT-B1 (Black)
UPC
810074846240 (White) / 810074846257 (Black)
EAN
5056547206189 (White) / 5056547206196 (Black)
